| Model | FS-10 | FS-12 | FS-13 | FS-15 | |
|
Spectroscopic method
|
Transmission Grating
|
Transmission Grating
|
Transmission Grating | Transmission Grating | |
|
Spectral Range
|
400-700nm
|
400-1000nm | 400-1000nm |
900-1700nm
|
|
|
Spectral band
|
600
|
1200 | 1200 | 254 | |
|
Spectral FWHM
|
2.5nm
|
2.5nm | 2.5nm | 8nm | |
|
Slit width
|
25um
|
25um | 25um | 25um | |
|
Transmission efficiency
|
>50%
|
>60% | >60% | >60% | |
|
Stray light level
|
<0.5%
|
<0.5% | <0.5% | <0.5% | |
|
Spatial Pixels
|
1920
|
1920 | 1920 | 320 | |
|
Pixel size
|
5.86um
|
5.86um | 5.86um |
30um
|
|
|
Imaging speed
|
Full band 41Hz
390Hz after ROI
|
Full band 41Hz
390Hz after ROI
|
Full band 41Hz
390Hz after ROI
|
200Hz | |
|
Detector
|
CMOS
|
CMOS
|
CMOS
|
InGaAs
|
|
|
SNR(Peak)
|
500/1
|
600/1 | 600/1 | 600/1 | |
|
Output
|
USB3.0
|
USB3.0 | USB3.0 |
Gigabit network
|
|
|
Interface
|
C-Mount
|
C-Mount | C-Mount | C-Mount | |
|
Accessories
|
USB3.0Transmission line
|
USB3.0Transmission line
|
USB3.0 Transmission line |
Gigabit network
|
|
|
ROI
|
Single area
|
Single area
|
Multi area | Single area | |
