Model number
|
FS-17
|
|
Spectroscopic method
|
grating
|
|
Spectral range
|
900-1700nm
|
|
Spectral channel
|
1024
|
|
Spectral resolution (FWHM)
|
6nm
|
|
Slit width
|
25um
|
|
Transmission efficiency
|
> 60%
|
|
Stray light
|
< 0.5%
|
|
Number of spatial pixels
|
1280
|
|
Pixel size
|
5um
|
|
Imaging speed
|
8bit/1024 bands 132 frames/SEC,12bit/1024 bands 70 frames/SEC,8bit/512 bands 253fps, up to 1800fps after ROI
|
|
Probe
|
InGaAs
|
|
SNR(Peak)
|
600/1
|
|
Camera output
|
start
|
|
Camera interface
|
C-Mount
|
|
Attachment
|
Lens, USB cable, power supply
|
|
ROI
|
Multiple regions
|
|
Dimension
|
Length x width x height :16.6cmx7.5cmx7.4cm
|
|
Weight
|
625g
|
|
Power dissipation
|
5W
|
