可見頻譜/NIR：
SW-NIR：
| Serial number | Index | Parameter |
| 1 | Spectral range | 400-1000nm |
| 2 | Spectral band | 1200 |
| 3 | Spectral FWHM | 2.5nm |
| 4 | Slit width | 25um |
| 5 | Transmission efficiency | >60% |
| 6 | Stray light | <0.5% |
| 7 | Spatial pixel number | 1920 |
| 8 | Pixel size | 5.86um |
| 9 | Imaging speed | Full band 128Hz 3300Hz can be achieved after ROI |
| 10 | Detector | CMOS |
| 11 | SNR(Peak) | 600/1 |
| 12 | Camera output | USB3.0 |
| 13 | Camera interface | C-Mount |
| 14 | Accessories | USB3.0 transmission line |
| 15 | ROI | Single area |
| 16 | Dimension | Length x width x height: 22.8 cmx7cmx8. 6 cm |
| 17 | Weight | 1250g |
| 18 | Power dissipation | 5 w |
| Serial number | Content | Serial number | Content |
| 1 | Hyperspectral Camera *1 | 7 | Power cord *1 |
| 2 | White calibration board *1 | 8 | charger*1 |
| 3 | 25mm lens *1 | 9 | Warranty card*1 |
| 4 | Test Bench *1 | 10 | User manual*1 |
| 5 | USB flash drive*1 | ||
| 6 | USB 3.0 data cable*1 |
