手機號: FS-60C
型號NO.: FS62C
Spectral Channel Number: 1024
Spectral Resolution (FWHM): 6.5nm
Slit Width: 25um
Number Of Spatial Pixels: 1280
Pixel Size: 5um
Imaging Speed: Full band 70Hz, maximum 1800Hz
Probe: InGaAs
Signal-to-noise Ratio: 600/1
Exportation: start
Camera Interface: C-Mount
ROI: Multiple regions
Attachments: Reflectance calibration board
Transport Package: Carton
Specification: Spectroscopic method: Transmission grating
Trademark: CHNSpec
Origin: China
HS編碼: 9027509090
After-sales Service: 10 Years
Warranty: 1 Year
Spectral Range: 900-1700nm
Currency: about shipping cost and estimated delivery time.
| 銷售組織: | Piece/Pieces |
The file is encrypted. Please fill in the following information to continue accessing it
|
Model number
|
FS-62C |
|
Spectroscopic method
|
Transmission grating
|
|
Spectral range
|
900-1700nm
|
|
Spectral channel number
|
1024
|
|
Spectral resolution (FWHM)
|
6.5nm
|
|
Slit width
|
25um
|
|
Transmission efficiency
|
>60%
|
|
Stray light
|
<0.5%
|
|
Number of spatial pixels
|
1280
|
|
Pixel size
|
5um
|
|
Imaging speed
|
Full band 70Hz, maximum 1800Hz
|
|
Probe
|
InGaAs
|
|
Signal-to-noise ratio
|
600/1
|
|
Exportation
|
start
|
|
Camera interface
|
C-Mount
|
|
Attachment
|
Lens, USB cable, power supply
|
|
ROI
|
Multiple regions
|
|
Built-in processing unit
|
Windows operating system, 8GB of RAM 512GB SSD and camera integrated Design (optional 1TB)
|
|
Heat dissipation mode
|
Internal air cooling heat dissipation
|
|
Mode of operation
|
Easy to operate, no need for professional drone operation Hand control, can achieve single operation
|
|
Observation mode
|
Real-time observation of aircraft sampling sites, hyperspectral images and spectral data by ground stations
|
|
Correction mode
|
Radiometric correction, reflectivity correction, and area correction support batch processing
|
|
Data format
|
Compatible with spe, hdr, and scp formats
|
|
Camera size
|
Less than 135*82*100 mm (L * W * H)
(Including lens and built-in embedded data acquisition and processing unit, excluding head)
Less than 190*129*100 mm (L * W * H)
(Including lens and built-in embedded data acquisition and processing unit, including head)
|
|
Camera weight
|
≤ 740g (including lens and built-in embedded data acquisition and processing unit, excluding PTZ)
≤ 1085g (including lens and built-in embedded data acquisition and processing unit, including head)
|
|
Attachments
|
Reflectance calibration board
|
|
Lens focal length
|
25mm
|
|
Camera scene
|
>25°
|
|
Application software
|
FIGSPEC UAV real-time flight control software,FIGSPEC Merge puzzle software,
FIGSPEC Studion image analysis software
|
