| Serial number | Index | Parameter |
| 1 | Image resolution | 320*320 |
| 2 | Dynamic range | 14 bits |
| 3 | Imaging speed | ≤5 seconds |
| 4 | Spectral channels number | 254 |
| 5 | Spectral region | 900-1700nm |
| 6 | Spectral FWHM | 8nm |
| 7 | Pixel size | 5.86um*5.86um |
| 8 | Detector type | CMOS |
| 9 | Auxiliary imaging features | Auxiliary framing camera to monitor the shooting area |
| 10 | Detector | CMOS |
| 11 | Sensor imaging surface size | 9.6mm*7.68mm |
| 12 | Standard lens focal length | 25mm |
| 13 | Minimum working distance | 100mm-∞ |
| 14 | Field angle | 17° |
| 15 | Minimum exposure time | 1us |
| 16 | Maximum exposure time | 1 seconds |
| 17 | Data interface | Gigabit ethernet |
| 18 | Camera lens interface | C |
| 13 | Accessories | Gigabit Ethernet transmission line |
| 14 | Imaging features | With ROI function Single area ROI can be achieved |
| 15 | Weight** | Less than 2.8KG |
| 16 | Host engine size * | 33.5cm*18.2cm*14.3cm |
| Serial number | Content | Serial number | Content |
| 1 | Hyperspectral Camera *1 | 7 | User manual*1 |
| 2 | White calibration board *1 | 8 | charger*1 |
| 3 | 25mm lens *1 | 9 | Warranty card*1 |
| 4 | Power cord *1 | ||
| 5 | USB flash drive*1 | ||
| 6 | USB 3.0 data cable*1 |
