Model number
|
FS-27
|
|
Spectroscopic method
|
Transmission grating
|
|
Image resolution
|
1280 * 1280
|
|
Dynamic range
|
12 bits
|
|
Imaging speed
|
≤ 5s
|
|
Spectral channel
|
1024
|
|
Spectral range
|
900-1700nm
|
|
Spectral resolution (FWHM)
|
6nm
|
|
Slit width
|
25um
|
|
Transmission efficiency
|
> 60%
|
|
Stray light level
|
< 0.5%
|
|
Pixel size
|
5um*5um
|
|
Detector type
|
InGaAs
|
|
Sensor imaging surface dimensions
|
9.6mm x 7.68mm
|
|
Standard lens focal length
|
25mm
|
|
Minimum working distance
|
150mm
|
|
Field Angle
|
14.5 °
|
|
Minimum exposure time
|
1us
|
|
Maximum exposure time
|
Ten seconds
|
|
Signal-to-noise ratio
|
600/1
|
|
Data interface
|
start
|
|
Camera interface
|
C-Mount
|
|
Attachment
|
USB3.0 transmission line
|
|
Imaging function
|
Have ROI capability Multiple regional ROIs can be achieved
|
|
Auxiliary imaging function
|
Auxiliary view camera to realize the monitoring of the shooting area
|
|
Power supply mode
|
Built-in battery power
|
|
Dimension
|
Length x width x height :24.8cm*14.5cm*14.5cm
|
|
Weight
|
2535g
|
|
Power dissipation
|
50W
|
