手機號: FS-22
型號NO.: FS-22
Spectral Channel Number: 300
Spectral Resolution Of Spectral Camera: Better than 5nm
Slit Width: 25um
Transmission Efficiency: more than 60%
Stray Light: less than 0.5%
Image Resolution: 1920*1920
Pixel Size: 5.86um*5.86um
Imaging Speed: less than 15 seconds
Detector Type: CMOS
SNR(Peak): 600/1
Camera Output: USB3.0
Camera Interface: C-Mount
Accessories: USB3.0 transmission line
ROI: Single area
Transport Package: Carton
Specification: 25.5cm*13.8cm*10.7cm
Trademark: CHNSpec
Origin: China
HS編碼: 9027509090
After-sales Service: 10 Years
Warranty: 1 Year
Spectral Camera Spectral Range: 400-1000nm
Currency: about shipping cost and estimated delivery time.
| 銷售組織: | Piece/Pieces |
The file is encrypted. Please fill in the following information to continue accessing it
| Serial number | Index | Parameter | |
| 1 | Image resolution | 1920*1920 | |
| 2 | Dynamic range | 12 bits | |
| 3 | Imaging speed | ≤15 seconds | |
| 4 | Spectral channels number | 300 | |
| 5 | Spectral region | 400-1000nm | |
| 6 | Spectral FWHM | 5nm | |
| 7 | Pixel size | 5.86um*5.86um | |
| 8 | Detector type | CMOS | |
| 9 | Auxiliary imaging features | Auxiliary framing camera to monitor the shooting area | |
| 10 | Detector | CMOS | |
| 11 | Sensor imaging surface size | 11.3*7.1mm | |
| 12 | Standard lens focal length | 25mm | |
| 13 | Minimum working distance | 150mm-∞ | |
| 14 | Field angle | 25° | |
| 15 | Minimum exposure time | 34us | |
| 16 | Maximum exposure time | 10 seconds | |
| 17 | Data interface | USB3.0 | |
| 18 | Camera lens interface | C-Mount | |
| 13 | Accessories | USB3.0 transmission line | |
| 14 | Imaging features | With ROI function Single area ROI can be achieved | |
| 15 | Weight** | Less than 2.8KG | |
| 16 | Host engine size * | 25.5cm*13.8cm*10.7cm |
| Serial number | Content | Serial number | Content |
| 1 | Hyperspectral Camera *1 | 7 | User manual*1 |
| 2 | White calibration board *1 | 8 | charger*1 |
| 3 | 25mm lens *1 | 9 | Warranty card*1 |
| 4 | Power cord *1 | ||
| 5 | USB flash drive*1 | ||
| 6 | USB 3.0 data cable*1 |
