| Index | Parameter |
| Spectral range | 400-1000nm |
| Spectral resolution | Better than 2.5nm |
| Image resolution | 1920 * 1920 |
| Number of spatial channels of spectral camera | 480/960/1920 |
| Number of spectral channels | 1200 |
| Dynamic range | 12bits |
| Slit width | 25 um |
| Pixel size | 5.86um* 5.86um |
| Detector type | CMOS |
| Standard lens focal length | 25 mm |
| Minimum working distance | 100mm |
| Field Angle | 25 ° |
| Minimum exposure time | 21us |
| Maximum exposure time | 10s |
| Signal-to-noise ratio | 600/1 |
| Data interface | USB3.0 |
| Auxiliary imaging function | The auxiliary view camera monitors the shooting area |
| PTZ working hours | 4 hours |
| Camera lens interface | C |
| Serial number | Content | Serial number | Content |
| 1 | Hyperspectral Camera *1 | 7 | Power cord *1 |
| 2 | White calibration board *1 | 8 | charger*1 |
| 3 | 25mm lens *1 | 9 | Warranty card*1 |
| 4 | Lens securing screw *1 | 10 | User manual*1 |
| 5 | USB flash drive*1 | ||
| 6 | USB 3.0 data cable*1 |
