手機號: FS-50/120
| 銷售組織: | Piece/Pieces |
The file is encrypted. Please fill in the following information to continue accessing it
| Serial number | Index | Parameter |
| 1 | Spectral range | 400-1000nm Per 5nm Output a wavelength |
| 2 | Spectral channel number | 120 |
| 3 | Spectral resolution (FWHM) | 2.5nm |
| 4 | Slit width | 25um |
| 5 | Spatial resolution | 1920 |
| 6 | Sampling rate | 128 line/S |
| 7 | Image sensor | 1/1.1 inch CMOS |
| 8 | Effective pixel | 1920 |
| 9 | Shutter type | Global shutter |
| 10 | Quantization number | 12bit |
| 11 | Visual field | 25.36 ° |
| 12 | Ground resolution | 2.8 cm @ h120m |
| 13 | Covering width | 54m@h120m |
| 14 | Optical window | High transmittance optical glass window |
| 15 | Main engine size | ≤155*95*119mm |
| 16 | Main engine weigh | ≤840g |
| 17 | Installation/power supply por | X-Port |
| 18 | Work loss | 45w |
| 19 | Picture forma | 12bit.SPE (compatible with third party analysis software such as envi) |
| 20 | Data storage space | 512SSD |
| 21 | Application software | FIGSPEC UAV real-time flight control software, FIGSPEC Merge puzzle software, FIGSPEC Studion image analysis software |
| 22 | Shooting method | Real-time acquisition |
| Serial number | Content | Serial number | Content |
| 1 | Camera host *1 | 7 | Packing List *1 |
| 2 | Adapter 12V 3A *1 | 8 | Reflectivity Board*1 |
| 3 | HDMI high-definition cable 0.5 meters *1 | 9 | Reflectivity Cloth*1 |
| 4 | Standard lens *1 | ||
| 5 | USB flash drive*1 | ||
| 6 | Certificate of Conformity & Warranty Card*1 |
